ETrack is among the best in class design tracking systems, with numerous built-in intelligence acquired by reach experience of Team EDS.

Parameters	ETrack-100	ETrack-201	ETrack-312	ETrack-442	ETrack-522	ETrack-OBD
Digital Input	1	1+1	1+2	1+3	1+4	-
Analog Input	0	0	1	4	2	-
Digital Output	0	1	2	2	2	-
2-Way Audio	No	No	No	Yes	No	No
Accelerometer & Gyro	No	No	No	Yes	Yes	Optional
Dual SIM & Multi Operator	No	No	No	Yes	Yes	Optional
SIM TYPE	Plastic	E-SIM & Plastic	Plastic	Dual Plastic	E-SIM & Plastic	Plastic
Communication	N.A	CAN	RS-232	USB + RS-232	RS-232	N.A
Driver Behaviour	No	No	No	Yes	Yes	Optional
Vehicle Health	No	No	No	No	No	Yes

Hard, Compact, Light-weight unit with Environment friendly IP67 or IP65 plastic casing
Smart data acquisition – Optimized based on Event, Time, Angle, Ignition & Distance
GPS Dark zone / multi path elimination using LBS & Cell Tower Triangulation
Virtual trip meter with automatic Trip start and Trip end detection
Power / SIM / Battery & Box Tamper detection & Emergency (SOS) Alerts
Configurable SMS Alerts from device on Tampering, Over speeding or Vehicle Towing
Remote Log maintenance and support using SMS
Device can be configured to hit multiple servers for a single event
Vehicle health & Behaviour Monitoring (OBD-II)
Driver Behaviour Monitoring
Configuration parameters can be updated through SMS
Configuration Parameters protected by Authenticate Password / Master number.
Configurable SMS Alerts.
Auto APN Setting overridden by manual APN Setting
Supports Multi-Operator (Up to 4 Operator Profiles)
Supports Dual- Sim (Plastic SIM + M2M SIM)
Reverse Geo-Address from device (optional)
Events from I/O elements detection and sending via GPRS or SMS
5 Circular Geo-fencing inside device
Internal / External Battery monitoring
Generate Alerts for Internal / External Battery low voltage level
Configurable External & Internal Battery Cut-off
Complete auto cut-off from vehicle battery to prevent battery discharge
Automated FOTA (firmware updating via GPRS in moving condition)

Parameters	Rating
Power Input	8V DC to 36V DC / 95V DC
Current Consumption	Normal ~ 60mA; Peak ~ 2.5A; Sleep ~ 1mA
Internal Battery - Backup Time	900 / 1100 / 3000mAH – Backup 4 Hour to 72 Hour
Operating Temp (Storage Temp)	0°C to +85°C (-10°C to +85 °C)
CPU	ARM Cotex-M3 / ARM Cotex-M0
External Memory	8/16 MB Flash
Wired Communication	1 RS-232 Port (excl. 2xx model & OBD), 1 USB Device (Optional)
GSM /GPRS MODEM	850/900/1800/1900 MHz Quad Band, Multi Slot (12/10/8), Class B GPRS Module
Navigation – GPS + GLONASS + IRNSS Receiver	GPS - L1 1575.42MHz C/A Code \n GLONASS – L1 1598.0625~1605.275MHz
Serial Interface	CCTV Camera/RFID/Biometrics Sensors (Optional)
GSM/GPS Antenna	Internal
